high intensity 20Khz Ultrasonic Liquid processing Homogenizing
Description:
RPS-Sonics manufactures the most technologically advanced and reliable ultrasonic processors in the industry for applications such as: dispersion of nanoparticles, nanotubes and Graphene; cell lysing and cell disruption; sample prep; ChIP assay; homogenization; extraction; atomization; and more.
The generator produce ultrasonic mechanical energy to the horn to make more than 20000 times vibration per seconds,
These energy can not only stimulate or promote many chemical reactions, to speed up chemical reaction, can even change the direction of some chemical reaction, generate some unexpected effects and miracles. Generally considered the stems mainly from the phenomena of ultrasonic mechanical and cavitation effect, is that they change the result of the reaction conditions and the environment.
20 KHZ frequency of ultrasonic industry application, already been proved that it is the most efficient, and has large-scale application.Ultrasound in liquid medium, by mechanical action, cavitation effect and heat effect, produce mechanical, thermal, optical, electrical, and chemical and so on a series of effects. Especially high power ultrasonic, can produce strong cavitation, and thus formed in the local instantaneous high temperature, high pressure, vacuum and micro jet.
Probe sonication is significantly more powerful and effective when compared to ultrasonic cleaner baths for nanoparticle applications. A cleaner bath requires hours to accomplish what a probe Sonicator can do in minutes. Sonicators can create a stable dispersion that can remain in suspension for many months as evidenced in this article excerpt:
Dispersions in vials (a) have coagulated CNTs in the body and at the bottom by means of bath sonication for 8 hours, (b) appear free-homogenous with probe sonication for 3 minutes, and (c) keep free-homogenous even after 4 months of sitting at room temperature. The concentration of Multi-Walled Carbon Nanotubes (MWCNTs) is 2500 mg/L and the MWCNTs/SDS ration is 1:10. (d) MWCNTs of (c) was diluted to 25 mg/L with deionized water.
| Item | Parameter |
| Frequency | 40Khz |
| Power | 500W |
| Capacity | 2L |
| Horn diameter | 8mm |
| Probe dip depth | 80mm |
Applications:
Ultrasonic have extremely capable and versatile, it can safely process a wide range of organic and inorganic materials – from microliters to liters. Typical applications include: sample preparation, dispersion, cell lysing, desegregation, homogenization, particle size reduction, soil testing, transesterification (including biodiesel production), nanotechnology (including nanoparticle and Graphene dispersion), acceleration of chemical reactions, degassing and atomization.
The new digital ultrasonicator is a powerful ultrasound processor for liquid treatments on bench-top and industrial scale. Common applications include homogenization, emulsification, dispersing & particle fine milling, lysis & extraction, dissolving vagy sonochemical reactions such as sono-synthesis and sono-catalysis. Touch display, browser remote control, automatic data recording. High Power and Full Process Control Powerful sonication is the process solution for manifold liquid processing applications, such as emulsifying, dispersing, milling vagy dissolving. The equipment provides intense ultrasound waves to fulfill demanding tasks without problems. To ensure a consistent process quality, not only the power delivered is essential, the control and monitoring of all important process parameters is key. The new generation of hdT ultrasonicators enables the operator to pilot the ultrasonic device via touch display or browser remote control.
The range of application of sonochemistry reactor:
• Dispersion
• Cell disruption
• Pharmacy sample prep
• Homogenization
• Emulsification
• Nanoparticle dispersion
• Atomization
• Graphene dispersion
• Biodiesel making;
• Liquidation,
• Crystallization,
• Extraction,
• Wastewater treatment,
• Accelerated reaction,
• kill microbes(cell disruption),
• Degradation of toxic organic pollutants
• antiscaling descaling in sewage treatment field
The following sonochemical effects can be observed in chemical reactions and processes:
• increase in reaction speed
• increase in reaction output
• more efficient energy usage
• sonochemical methods for switching of reaction pathway
• performance improvement of phase transfer catalysts
• avoidance of phase transfer catalysts
• use of crude or technical reagents
• activation of metals and solids
• increase in the reactivity of reagents or catalysts
• improvement of particle synthesis
• coating of nanoparticles
Before ultrasonic homogenize
After ultrasonic homogenize
